12CH CCWDM MUX/DEMUX, Compact CWDM Modules

More Views

12CH CCWDM MUX/DEMUX, Compact CWDM Modules


Availability: In stock

Volume Price: Inquire
●Compact Size (Customized)
●Unidirectional & Bidirectional WDM
●ITU Frequency Grid
●Ultra Stable & Highly Reliable
●Wave Length: 1270nm ~ 1610nm

* Required Fields

Product Description Shipping & Payment Customer Reviews


Compact Coarse Wavelength Division Multiplexer (CCWDM) is expanding the bandwidth of Metro/Access communications networks. 10Gtek's CCWDM is based on thin film filter technology and metal bonding micro optic packaging. It operates at 20nm channel spacing ITU Grid CWDM wavelengths
from 1270nm to 1610nm.

10Gtek provides high quality CCWDM with flat channel bandwidth, flexible channel configuration, low insertion loss and high isolation. It is designed to upgrade capacity easily as the system grows. All 10Gtek products are epoxy-free in the optical path.

● Low Insertion Loss

● Compact size

● Ultra Stable and Highly Reliable

● Extended Operating Temperature Available


● Optical Add/Drop Multiplexing

● Telecom networks

● Metro networks

● Broadband Networks

● Please note that only ABS form factor is available (Min. size: 100mm x 80mm x 10mm), when adding monitor port to this product

Performance Specifications:
Parameters 4CH


8CH 8+UPG1 8+UPG2
Operating Wavelength (nm) 1260 ~ 1620 1260 ~ 1620 1260 ~ 1620 1260 ~ 1620 1260 ~ 1620
Channel Wavelength (nm) 1270, 1290, ..., 1590, 1610 or 1271, 1291, ..., 1591, 1611
Channel Spacing (nm) 20 20 20 20 20
Channel Passband (nm) CWL+/-6.5nm CWL+/-6.5nm CWL+/-6.5nm CWL+/-6.5nm CWL+/-6.5nm
Insertion Loss (dB) ≤1.5 ≤1.5 ≤1.8 ≤1.8 ≤2.0
Channel Ripple (dB) ≤0.4 ≤0.4 ≤0.4 ≤0.4 ≤0.4
Isolation Adjacent (dB) >30 >30 >30 >30 >30
Isolation Non-adjacent (dB) >40 >40 >40 >40 >40
Polarization Mode Dispersion (PS) ≤0.2 ≤0.2 ≤0.2 ≤0.2 ≤0.2
Polarization Dependent Loss (dB) ≤0.2 ≤0.2 ≤0.2 ≤0.2 ≤0.2
Directivity (dB) >45 >45 >45 >45 >45
Return Loss (dB) >45 >45 >45 >45 >45
Maximum Power handling (mW) 500 500 500 500 500
Operating Temperature (°C) -5 ~ +70 -5 ~ +70 -5 ~ +70 -5 ~ +70 -5 ~ +70
Storage Temperature (°C) -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85 -40 ~ +85
Fiber Type G657A1 G657A1 G657A1 G657A1 G657A1
Package Dimension (mm) L55 x W45 x H6, ABS Box Min. Size: 100mm x 80mm x 10mm
*Specifications mentioned above are for device without connector.


Order Information:


Part Number Channel No.

Wave Length

Pigtail Type Fiber Length Connector
CCWDM04 4 Channel 1270nm, 1290nm,.......1590nm, 1610nm 250um
CCWDM06 6 Channel
CCWDM08 8 Channel
CCWDM10 10 Channel
CCWDM12 12 Channel
CCWDM14 14 Channel
CCWDM16 16 Channel
CCWDM18 18 Channel
